Effect of Cross-Sectional Designs of Different Ni-Ti Files on Shaping Ability After Repeated Usage in Simulated Root Canals.


  • Fikrat Shawqi Qaddori Directorate of Health, Erbil, Iraq.
  • Raid Fahim Salman Department of Conservative Dentistry, College of Dentistry, Hawler Medical University, Erbil, Iraq.




Cross-sectional design, Shaping ability, Nickle Titanium rotary files, 2 Shape, K3-i File, E3 Azure, Neolix


Background and Objective: The study aimed was to compare the effect of cross-sectional designs of five rotary systems (One Curve, 2Shape, K3-i File, E3 Azure, Neolix), on the shaping ability of the files in simulated resin blocks under controlled conditions with five repeated use. The shaping ability of the files includes the following variables: (1) Longitudinal sectional area difference, (2) Canal wall surface area difference, (3) Canal volume difference, (4) SMI (structure material index) difference, (5) Cross-sectional area difference.

Methods: Five rotary file systems: (1) One Curve, (2) 2Shape, (3) K3-i File, (4) E3 Azure, (5) Neolix, were tested in simulated J-shaped root canal resin blocks with a 45˚ angle of curvature. 10 files from each system, each one of the 10 files were used to prepare 5 resin blocks, named R1-R2-R3-R4-R5. All the used files from the 5 systems had tip size 25 diameter, and taper (6%), and length (25 mm). The first 4 rotary systems were used with a fixed speed (350 rpm), and fixed torque (3 Ncm), except for the fifth system which was used with a speed of (500 rpm), and torque (4 Ncm). All the 250 resin blocks were prepared for Glide Path with manual reamers size 10, and 15, with a fixed working length 16 mm, then all the 250 samples were prepared with a Proglider rotary file from Dentsply (size 16 taper 3%), then finally were prepared with Edge Files (USA), with size 20 and taper 6%, reaching to the step of master preparation with the selected files of the 5 systems.

Results: In the first, second, third, and fourth variables a statistically non-significant difference (P > 0.05) was found between One curve and 2Shape, a statistically significant difference (P < 0.05) was found between One Curve, K3-i File, E3 Azure, and Neolix. About the fifth variable which is the Cross-sectional area difference: the study compared the difference between the cross-section area of the canal at the point D8, comparing the cross-section area before and after preparation using ANOVA test and Post hoc test, a statistically significant difference (P < 0.05) was found between the Neolix and (2shape, K3 i-File, and E3 Azure).

Conclusion: The cross-sectional design of the endodontic rotary instrument had an obvious effect on the shaping ability of the system.


Campbell F, Cunliffe J, Darcey J. Current technology in endodontic instrumentation: advances in metallurgy and manufacture. Br Dent J. 2021 Jul;231(1):49–57.

Donnermeyer D, Viedenz A, Schäfer E, Bürklein S. Impact of new cross-sectional designs on the shaping ability of rotary NiTi instruments in S-shaped canals. Odontology. 2020 Apr 1;108(2):174–9.

Zhang EW, Cheung GSP, Zheng YF. Influence of Cross-sectional Design and Dimension on Mechanical Behavior of Nickel-Titanium Instruments under Torsion and Bending: A Numerical Analysis. J Endod. 2010 Aug;36(8):1394–8.

Ha JH, Cheung GSP, Versluis A, Lee CJ, Kwak SW, Kim HC. “Screw-in” tendency of rotary nickel-titanium files due to design geometry. Int Endod J. 2015 Jul;48(7):666–72.

Staffoli S, Grande NM, Plotino G, Özyürek T, Gündoğar M, Fortunato L, et al. Influence of environmental temperature, heat-treatment and design on the cyclic fatigue resistance of three generations of a single-file nickel-titanium rotary instrument. Odontology. 2019 Jul;107(3):301–7.

One Curve [Internet]. Micro-Mega. [cited 2022 May 7]. Available from: https://micro-mega.com/shaping/one-curve/?lang=en

Uslu G, Özyürek T, Gündoğar M, Yılmaz K. Cyclic fatigue resistance of 2Shape, Twisted File and EndoSequence Xpress nickel-titanium rotary files at intracanal temperature. J Dent Res Dent Clin Dent Prospects. 2018;12(4):283–7.

2Shape [Internet]. Micro-Mega. [cited 2022 Jun 12]. Available from: https://micro-mega.com/shaping/2shape/?lang=en

Endostar [Internet]. Endostar. [cited 2022 Jun 16]. Available from: https://www.endostar.eu/en/produkty/endostar-e3-azure-basic-en/

Fráter M, Jakab A, Braunitzer G, Tóth Z, Nagy K. The potential effect of instrumentation with different nickel titanium rotary systems on dentinal crack formation—An in vitro study. Kielbassa AM, editor. PLOS ONE. 2020 Sep 9;15(9): e0238790.

Faisal I, Saif R, Alsulaiman M, Natto ZS. Shaping ability of 2Shape and NeoNiTi rotary instruments in preparation of curved canals using micro-computed tomography. BMC Oral Health. 2021 Nov 19;21(1):595.

Khalilak Z, Fallahdoost A, Dadresanfar B, Rezvani G. Comparison of Extracted Teeth and Simulated Resin Blocks on Apical Canal Transportation. Iran Endod J. 2008;3(4):109–12.

De Oliveira Alves V, da Silveira Bueno CE, Cunha RS, Pinheiro SL, Fontana CE, de Martin AS. Comparison among Manual Instruments and PathFile and Mtwo Rotary Instruments to Create a Glide Path in the Root Canal Preparation of Curved Canals. J Endod. 2012 Jan;38(1):117–20.

Atav Ateş A, Arıcan B. Shaping efficiency of WaveOne Gold and One Curve in simulated J-shaped root canals. East J Med. 2021;26(2):242–7.




How to Cite

Qaddori FS, Salman RF. Effect of Cross-Sectional Designs of Different Ni-Ti Files on Shaping Ability After Repeated Usage in Simulated Root Canals. EDJ [Internet]. 2024 Jun. 6 [cited 2024 Jul. 20];7(1):1-9. Available from: https://edj.hmu.edu.krd/index.php/journal/article/view/265
